Shortcut is the comma-key.īoard rotation: To turn the board by multiples of 90 degree.īoard mirroring: For horizontal or vertical mirroring of the board.Īutomatic layer dimming: With this slider you can increase the intensity of the items on the current layer. Using the big crosshair cursor may slow down the display performance a lot. MiscellaneousĬrosshair cursor: Here you can change from the standard small crosshair cursor to a big 45-degree crosshair cursor.
For the object types in the upper table you can choose the color for each layer individually. Here you can define the colors for displaying objects on the board by clicking the corresponding color field with the left button. If you push a slider to the left, all objects on the corresponding layer will get invisible.
With the sliders in this window you can adjust the intensity for displaying objects on each layer individually.
LAYOUTEDITOR MANUAL FULL
If you push the slider for an object type is to the right, objects of this type will get displayed with full intensity, if you push it to the left, objects of this type will become invisible. With the sliders in this window you can adjust the intensity for displaying the single object types.
If the violations were switched off before, they will be switched on and vice versa. Here you can switch on or off displaying the clearance violations. If the airlines were switched off before, they will be switched on and vice versa. Here you can switch on or off displaying the open connections as air lines. For all numeric inputs: The input is only confirmed by pressing the Enter key to avoid accidental changes.
